Model No.: GT-TF-XTA-65: Type: Interactive Touch Foil
Size：65 Inch: Drive Type: Drive Free
Screen Type: Capacitive
Place of Origin: China
Supply Ability: 1000000
Certificate: ISO9001 And ISO14001
HS Code: 8548900030
Our touch film is a new，transparent touch film,with high accuracy,easy to install on the glass,Acrylic or PC.This65 inch touch foil is the bigest interactive touch foil of our XTA series .If you're interesting in thisTouch Screen overlay film,we're worth your trust.
The principle of projected capacitive touch foil technology belongs to projected capacitive screen. It is composed of two transparent thin films, with a grid matrix layer of X and Y axes crisscrossed by metal wires.Each matrix forms an induction unit that can sense the touch of human hands.The hand's touch signal is transmitted to a microchip controller connected to the nanowires. The microcontroller transmits the signal through an interface to a computer, which recognizes the position of the touch on the screen.
XTA series channel 152, generally used for 32-65 inches, suitable for touch module, digital signage, outdoor advertising machine, game entertainment, new retail and other application scenarios. These application scenarios generally require stability and easy maintenance. Touch film XTA series is the first choice. Among them, game and entertainment scenes generally requiremore points and better waterproofing. XTA can be upgraded to 40 points, and large areas of water can also be touched.Touching without blind area and debugging only 1 minute.
1) Light weight, suitable to be laminated to glass /acrylic; 2) Transparent, no frame; 3) Accurate positioning; 4) No mechanical or pressure-sensitive elements, durable and stable; 5) Not sensitive to outer light, the change of light would not affect; 6) Multi-touch points (up to 50 touch points); 7) Simple & quick to install; 8) Glass up to 12mm thick; 9) High resolution controller.
GreenTouch provides a wide range of customization options that can meet your requirements, including touch points, screen size, FPC outlet location, length, LOGO, pasting services and custom glass cover surface treatment AG, AF, AR.
